Description
Specifications
POWER [watts/ch], 2 OHM STEREO
150 x 4
POWER [watts/ch], 4 OHM STEREO
75 x 4
POWER [watts/ch], 4 OHM BRIDGED MONO
300 x 2
DYNAMIC POWER [watts]
725
Dimensions [in] all models 2-5/16H x 7-1/8W x ___L
12-7/16
Dimensions [cm] all models 5.9H x 18.0W x ___L
31.5
FREQUENCY RESPONSE [Hz]
10-20k, +0/-1dB
INPUT SENSITIVITY
High Level 250mV-10V
Low Level 125mV-5V
SIGNAL-TO-NOISE RATIO
>95dB, a-weighted, re: rated power
ACTIVE CROSSOVER
12dB/octave, variable 50-200Hz, selectable high pass, low pass or all pass
KickEQ™ BOOST
Variable 0-6dB, centered @ 40Hz
RMS Power test @ 14.4v @ </- 1% THD+N, Audio Precision® APx500 analyzer, see www.kicker.com/amp-power-testing for details.
Dynamic Power test @ 14.4v @ </- 10% THD+N, Audio Precision APx500 analyzer, see www.kicker.com/amp-power-testing for details.
Audio Precision is a registered trademark of Audio Precision in the United States and other countries.
