Thiele/Small Parameters
48CWRT102 T/S Parameters
SIZE [in, cm]:
10, 25
IMPEDANCE [Ohms]:
2 DVC
Recommended Amplifier Power (watts RMS)
400
Peak Power (watts, per ANSI/CTA-2031-A)
800
SENSITIVITY [dB 1w/1m]:
84.8
MOUNTING DEPTH [in, cm]:
3-7/16, 8.8
MOUNTING DIAMETER [in, cm]:
9-1/8, 23.1
MIN SEALED BOX VOL [cu. ft, L]:
0.4, 11.3
MAX SEALED BOX VOL [cu. ft, L]:
1.25, 35 .4
MIN VENTED BOX VOL [cu. ft, L]:
1.25, 35.4
MAX VENTED BOX VOL [cu. ft, L]:
1.75, 49.6
*Assumes typical music program with minimal amplifier clipping; varies with enclosure size. See your KICKER dealer for details.
**Port Volume Excluded.
Due to continual development, product and specifications are subject to change without notice. Stillwater Designs and its agents are not responsible for typographical errors.
